Small Aerial Boom Lift – Mini Self-Propelled Vertical Work Platform
The Mini Self-Propelled Vertical Mast Lift with Jib is a compact and versatile aerial work platform designed to safely lift personnel and tools to elevated work areas. Ideal for maintenance, construction, and industrial tasks, it offers precision access in confined or hard-to-reach spaces.
*Self-Propelled Mobility
Operates independently without the need for towing or manual movement, enhancing efficiency and flexibility on job sites.
*Vertical Mast Design
The vertical mast provides stable, space-saving elevation, delivering reliable height access in tight indoor or outdoor environments.
*Articulating Jib Arm
The integrated jib offers additional outreach and articulation, allowing precise positioning over obstacles and into hard-to-access zones.
Standard configurations:
| ▲AC Driving Motor | ▲Proportional Joystick Controls | ▲Self-Locking Gates | ▲Drivable At Full Height |
| ▲Non-Marking Tires | ▲4 x 2 Drive | ▲Automatic Braking System | ▲Emergency Descent System |
| ▲Tubing Explosion-Proof System | ▲Fault Diagnosis System | ▲Tilt Sensor Alarm | ▲Motion Alarm |
| ▲345° Turret Rotation | ▲Horn | ▲Hour Meter | ▲Charging Protection System |
| ▲Flashing Beacon | ▲Automatic Pothole Protection | ▲Drive Enable | ▲Charging Indicator |
| ▲Manual Brake Release | ▲Lanyard Attachment Point | ▲Tie-Down And Lifting Points | ▲Platform Load Sense System |
| ▲Emergency Stop Button | ▲Swing Out Components Cover | ▲Overload Sensor Alarm |
Specification:
Model | CLP90J |
Max. Working Height | 11.2m |
Max. Platform Height | 9.2m |
Max. Horizontal Reach | 3m |
Up and Over Height | 7.89m |
| Guardrail Height | 1.1m |
| Overall Length | 2.53m |
| Overall Width | 1.0m |
| Overall Height(Stowed) | 1.99m |
| Platform Dimension | 0.62*0.87m |
| Ground Clearance(Stowed) | 70mm |
| Ground Clearance(Raised) | 19mm |
| Wheelbase | 1.22m |
| Loading Capacity | 200kg |
| Occupants | 2 |
| Turning Radius(Inside/Outside) | 0.23/1.65m |
| Turret Rotation | 345° |
| Jib Movement | 130° |
| Travel Speed(Stowed) | 4.5km/h |
| Travel Speed(Raised) | 0.5km/h |
| Up/Down Speed | 42/38s |
| Max. Working Slope | X-2.5° , Y-2.5° |
| Tyres | Φ381*127mm |
| Driving Motor | 24V/0.9kw |
| Lifting Motor | 24V/3kw |
| Battery | 24V/240Ah |
| Charger | 24V/30A |
| Weight | 2950kg |
